Batch control system magnetic flow meter water flowmeter

QTLD water flow meter is calibrated 5 points, test bench is approved ISO / IEC 17025:2015, standard accuracy is ¡À0.5%, ¡À0.2% accuracy is optional. magnetic flowmeter is widely used because less obstruction, cost-effective and accurate measurement. Magnetic flow meter don’t have any moving parts to wear down, reducing the need for maintenance or replacement.

Accuracy: ¡À0.5%
Repeatability: 0.17%
Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic

Magnetic flowmeter operate under the principle of Faraday’s Law of Electromagnetic Induction to measure liquid velocity. Following Faraday’s Law, magnetic flowmeters measure the velocity of conductive liquids in pipes, such as water, acids, caustic, and slurries. In order of usage, magnetic flowmeter use in water/wastewater industry, chemical, food and beverage, power, pulp and paper, metals and mining, and pharmaceutical application.

Size: 1/8″-120″
Accuracy: ¡À0.5%
Repeatability: 0.17%
Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote

Accuracy of electromagnetic flowmeter is ¡À0.5% standard, ¡À0.2% is optional, lelectromagnetic flow meter is calibrated on ¡À0.2% accuracy calibration device, inline magnetic flow meter is calibrationed 5 points by comparison method or mass method. our calibration lab has been approved CNAS ISO/IEC 17025:2017.

Size: DN3-DN3000
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Protection Grade: IP65 std, IP68 optional for remote
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery
Sensor material: carbon steel (std), SS304 / SS316 (optional)

Standard material of waste water flow meter is carbon steel, but client can chose stainless steel 304 or SS316.

The sensor with advanced processing technology and liquid airproof is of long
natural life and of nice resistance to shaking leakage.It guarantees the instrument
good precision and stability .

Pressure of QTLD water flow emter can be ANSI 150#, 300#, 600#, 900#, etc. all waste water flow meter will be tested by pressure equipment. QTLD water flow meter is calibrated by ISO/IEC 17025:2016 CNAS Approved Test Bench. it can be powered by AC/DC/3.6V lithium battery. Inline flow meter is widely used for conductive liquids which conductivity is high than 20 ¦ÌS/cm, size is DN3-DN3000, which can be used various pipes.
Size: 1/8″-120″
Accuracy: ¡À0.5%
Structure: compact, remote
Velocity: 0.1~15 m/s
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery
Sensor material: carbon steel (std), SS304 / SS316 (optional)
Measuring tube: SS304

GSM/GPRS remote monitoring management software system can query, count, analyze and display the water usage of each measuring point in the form of graphs or curves, so that users can conveniently manage the water used in each measuring point.

Electromagnetic water meter use a magnetic field to generate and channel liquid flow through a pipe. A voltage signal is created when a conductive liquid flows through the flowmeter¡¯s magnetic field.

Electromagnetic flowmeter consists of sensors and converters in two parts. The product is based on Faraday’s law of electromagnetic induction
Measure forward and reverse direction flows.
♦ Built-in reference electrodes,no need to connect ground ring.
♦ Dual frequency excitation and stable zero point.
Medium temperature:
Integral type : -20℃~60℃
Remote type(Rubber&Polyurethane liner): -10℃~80℃
Remote type (PTFE&PFA&F46 liner): -10℃~160℃
♦ Integrated verification,diagnostic function and empty pipe detection.
♦ Measure forward and reverse direction flows.

1) Intelligent empty pipe detection and electrodes resistance measurement diagnosing.
2) High definition LCD display with backlight.
3) 16 bits MCU, providing high integration and accuracy.

magnetic flowmeter has a large measurement scale, usually 10:1, and the optional flow scale is wide. electromagnetic flow meter is widely used because less obstruction, cost-effective and accurate measurement. and no other throttle valve components that hinder the fluidity of the liquid. Therefore it is not possible to cause any additional pressure damage when the liquid is.

Structure: compact, remote
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Velocity: 0.1~15 m/s
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery

Q&T series electromagnetic flow meter has a backlight and a wide temperature-ranged Chinese LCD display. With fully practical function, visual display, easy operation, it saves troubles for on-site installation operation and maintenance. Q&T series electromagnetic flow meter can be widely used in industrial fields such as petroleum, chemical, metallurgy, water supply and drainage, steel, coal, paper, food, textile, environmental protection and other municipal administration, water conservancy construction field etc.
Size: 1/8″-120″
Accuracy: ±0.5%
Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Protection Grade: IP65 std, IP68 optional for remote
Velocity: 0.1~15 m/s
Conductivity: > 5 μS/cm, demineralized water > 20 µS/cm
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery
Size: DN3-DN3000
Sensor material: carbon steel (std), SS304 / SS316 (optional)
Flange: ANSI, DIN, JIS, etc.
Measuring tube: SS304
Function: High and low alarm, exciting alarm, empty pipe alarm, self-diagnosis

Battery power electromagnetic flow meter used in process measurement and control, leak detection, etc.Insertion Battery Magnetic flow meter usually for large diameter above DN100 and save cost. Size: DN10-DN2000; Nominal Pressure: 0.6-1.6MPa (2.5Mpa / 4.0Mpa /6.4Mpa…Max 42Mpa); Accuracy: ¡À0.5% (Standard),¡À0.3% or ¡À0.2% (Optional); Liner:PTFE,Neoprene,Hard Rubber,EPDM,FEP,Polyurethane, PFA; Electrode: SUS316L,Hastelloy B,Hastelloy C,Titanium,Tantalum,Platinum-iridium; Protection Class: IP65(Standard),IP68(Optional for remote type); Output Signal: 4-20mA / pulse (optional); Communication: RS485(Optional),HART(Optional),GPRS/GSM(Optional);

Q&T Instrument is OEM for European and American clients for
magnetic flow meter. color, logo and company name can be customized. Pulse width of electromagnetic flow meter can be customized, standard cable is 10m, max length is 120m, electromagnetic flow meter is mainly used to measure beverage. liner can be PTFE or rubber, our magnetic flow meter have been approved CE-LVD, CE-EMC, ATEX, NSF, tec. it can mag flowmeter is calibrationed 5 points.

Accuracy: ¡À0.5%
Structure: compact, remote
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Protection Grade: IP65 std, IP68 optional for remote
Velocity: 0.1~15 m/s

Our magnetic flow meters are CE certificated, it is widely used for conductive liquids, our magnetic-inductive flow meters can be used for liquids and liquid/solid mixes (20 and 3 µS/cm) such as: water, pulps, pastes, slurries, acids, solvents, lyes, sap, emulsions, ore slurries, sand or water mixes.

Specifications:
Accuracy: ±0.5%
Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Protection Grade: IP65 std, IP68 optional for remote
Velocity: 0.1~15 m/s
Conductivity: > 5 μS/cm, demineralized water > 20 µS/cm
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery

Q&T offer 18 months warranty for Battery power electromagnetic flowmeter, Battery power magnetic flowmeter is easy to use, simple to install into position & no regular maintenance required. Nominal Pressure: 0.6-1.6MPa(2.5Mpa / 4.0Mpa /6.4Mpa…Max 42Mpa); Accuracy: ¡À0.5% (Standard), ¡À0.3% or ¡À0.2% (Optional); Liner: PTFE, Neoprene,Hard Rubber,EPDM,FEP, Polyurethane,PFA; Electrode: SUS316L,Hastelloy B,Hastelloy C, Titanium,Tantalum,Platinum-iridium; Structure: Integral,remote,submersible,ex-proof; Process Connection: Flange(Standard),Wafer,Thread,Tri-clamp etc(optional); Output Signal: 4-20mA / pulse (optional); Communication: RS485(Optional),HART(Optional),GPRS/GSM(Optional);

Electromagnetic water meter is composed of sensor and transducer.
Based on Faraday’s law of electromagnetic induction, it is used to measure the volume flow rate of conductive liquid with
conductivity greater than 5 S/cm. It is an inductive instrument for measuring the volume flow rate of conductive medium.
1. A variety of electrodes are available
2. High definition LCD display, easy to understand and operate.
3. Rotatable Screen
4.ANSI, DIN, JIS flange standards.
5. OEM, ODM, all customization are supported.

Battery power electromagnetic flow meter with IP68 protection, Battery power magnetic flow meter workable under water for few days, flow meter can add external 12-24 VDC power supply with 4-20mA. Size: DN10-DN2000; Nominal Pressure: 0.6-1.6MPa(2.5Mpa / 4.0Mpa /6.4Mpa…Max 42Mpa); Accuracy: ¡À0.5% (Standard), ¡À0.3% or ¡À0.2% (Optional); Structure: Integral,remote,submersible,ex-proof; Medium Temperature: -20¡æ~+60¡æ (integral type), Remote type(neoprene,Hard rubber,Polyurethane, EPDM) :-10¡æ~+80¡æ; Remote type (PTFE / PFA / FEP): -10¡æ~+160¡æ; Protection Class: IP65(Standard),IP68(Optional for remote type); Output Signal: 4-20mA / pulse (optional); Communication: RS485(Optional), HART(Optional), GPRS/GSM (Optional);

structurer is compact type and remote type with 10m cable standard and 120m max. hard rubber or Neoprene liner of magnetic flowmeter is configured for drinking water, Magnetic flow meters use a magnetic field to generate and channel liquid flow through a pipe. Q&T Instrument is ISO 9001:2015 manufacturer with 17 years producing experience, can meet clients’ various requirements.

Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Protection Grade: IP65 std, IP68 optional for remote
Velocity: 0.1~15 m/s
Conductivity: > 5 ¦ÌS/cm, demineralized water > 20 ¦ÌS/cm

With simple structure ,the flow meter is of high reliability without lining in the
measuring pipe .
The wide range of the nominal bore is suitable for all the pipe size between
DN2 and DN600.
Measurement is independent of fluid density ,viscosity ,humidity ,temperature
pressure and conductivity.

The measuring channel of the electromagnetic flowmeter is the lubricating straight pipe of the block flow detection piece. Because it is not easy to block, it can measure the liquid-solid phase fluid containing solid particles or fibers, such as pulp, coal water slurry, mineral pulp, mud and sewage, etc..

Size: 1/8″-120″
Accuracy: ¡À0.5%
Structure: compact, remote
Velocity: 0.1~15 m/s
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery
Sensor material: carbon steel (std), SS304 / SS316 (optional)
Measuring tube: SS304

Battery operated electromagnetic flowmeter with Infrared remote control display and operation, battery operated magnetic flow meter also realize bi-directional measurement easy installation. Accuracy: ¡À0.5% (Standard), ¡À0.3% or ¡À0.2% (Optional);
Protection Class: IP65(Standard),IP68(Optional for remote type);
Process Connection: Flange(Standard),Wafer,Thread,Tri-clamp etc(optional);
Output Signal: 4-20mA / pulse (optional);
Communication: RS485(Optional),HART(Optional),GPRS/GSM(Optional);
Power Supply: Battery powered 3.6V,Battery powered 3.6V +DC24V(Optional);
Power Consumption: 0.5W(Standard), 1.5W(with DC24V);
Explosion Proof: ATEX

Q&T series Electromagnetic flowmeter follows the faraday law of electromagnetic induction.When the conductive liquid flows through the electromagnetic flowmeter,the induced electromotive force will be produced in the conductor,and the induced electromotive force is directly proportional to the velocity of conductive liquid,magnetic flux density and width of conductor(inside diameter of flowmeter,such induced electromotive force is detected by a pair of electrodes on the tube wall of the flowmeter,and the rate of flow can be acquired by mathematical operation.
Size: 1/8″-120″
Accuracy: ±0.5%
Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Protection Grade: IP65 std, IP68 optional for remote
Velocity: 0.1~15 m/s
Conductivity: > 5 μS/cm, demineralized water > 20 µS/cm
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery
Size: DN3-DN3000
Sensor material: carbon steel (std), SS304 / SS316 (optional)
Flange: ANSI, DIN, JIS, etc.
Measuring tube: SS304
Function: High and low alarm, exciting alarm, empty pipe alarm, self-diagnosis

Battery power mag flow meter universally applicable for conductive liquids, Battery power electromagnetic flowmeter fully functional in remote areas without power, realize wireless measurement. Size: DN10-DN2000; Accuracy: ¡À0.5% (Standard), ¡À0.3% or ¡À0.2% (Optional); Structure: Integral,remote,submersible,ex-proof; Ambient Humidity: 5-100%RH (relative humidity); Protection Class: IP65(Standard),IP68(Optional for remote type); Process Connection: Flange(Standard),Wafer,Thread,Tri-clamp etc(optional); Output Signal: 4-20mA / pulse (optional); Communication: RS485(Optional),HART(Optional),GPRS/GSM(Optional);

No Moving Parts
RS485 Standard,HART standard is available.
Suitable for Pipes Up to DN300
Pulse, Gprs output
Standard 5 points calibration Included

electromagnetic BTU meter can be integrated type and split type, standard cable length is 10m. Pt1000 temerature sensor is configured. Magnetic energy meter is composed by transmitter, sensor and PT1000 temperature sensor, which can monitor flow and energy of hot water and cold water.

Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS

The insertion magnetic flowmeter is remote type with 10m cable, mainly used to large pipeline, it can be install with pressure. insertion mag flowmeter is used to measure the flow of conductive liquids. insertion magmeter, which allows sensor to be installed and retracted from process piping without shutting down the process. size is from 4″~240″

Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery
Size: DN3-DN3000
Sensor material: carbon steel (std), SS304 / SS316 (optional)
Flange: ANSI, DIN, JIS, etc.
Measuring tube: SS304
Function: High and low alarm, exciting alarm, empty pipe alarm, self-diagnosis

With simple structure ,the flow meter is of high reliability without lining in the
measuring pipe .
The wide range of the nominal bore is suitable for all the pipe size between
DN2 and DN600.
Measurement is independent of fluid density ,viscosity ,humidity ,temperature
pressure and conductivity.

A variety of electrodes and linings are available for a variety of complex working conditions.
It is unaffected by changes in temperature, density, viscosity, concentration and electrical conductivity.

Battery operated mag flow meter enjoy good accuracy with ¡À0.5%, 3.6V battery meter provides with 3-5 years continuous battery operation, flowmeter easy easy maintain in operation. Nominal Pressure: 0.6-1.6MPa (2.5Mpa / 4.0Mpa /6.4Mpa…Max 42Mpa); Accuracy: ¡À0.5% (Standard), ¡À0.3% or ¡À0.2% (Optional); Liner: PTFE,Neoprene,Hard Rubber,EPDM,FEP, Polyurethane,PFA; Electrode: SUS316L,Hastelloy B,Hastelloy C, Titanium,Tantalum,Platinum-iridium; Structure: Integral,remote,submersible,ex-proof; Medium Temperature: -20¡æ~+60¡æ (integral type), Remote type(neoprene,Hard rubber,Polyurethane, EPDM) -10¡æ~+80¡æ; Remote type (PTFE / PFA / FEP)-10¡æ~+160¡æ; Ambient Temperature: -20¡æ~+60¡æ; Ambient Humidity: 5-100%RH (relative humidity);
