Digital Electromagnetic Flowmeter Liquid Water Magnetic Flow Water Meter

Battery electromagnetic flow meter is an ideal solution for various kinds of conductive liquid,battery magnetic flowmeter eliminates the need for AC/DC power connection. Size: DN10-DN2000; Protection Class: IP65(Standard),IP68(Optional for remote type); Process Connection: Flange(Standard),Wafer,Thread,Tri-clamp etc(optional); Output Signal: 4-20mA / pulse (optional); Communication: RS485(Optional),HART(Optional),GPRS/GSM(Optional); Power Supply: Battery powered 3.6V, Battery powered 3.6V +DC24V(Optional); Power Consumption: 0.5W(Standard), 1.5W(with DC24V); Alarm: Upper limit alarm / lower limit alarm

Q&T series insert type electromagnetic flowmeter is on the basis of pipeline electromagnetic flowmeter developed a kind of new flow meter.
After adopting the technology of pressure opening and pressure installation, the plug-in electromagnetic flowmeter can be installed without stopping water, and can also be installed on cast iron pipes and cement pipes. The successful development of plug – in electromagnetic flowmeter provides a new method for fluid flow measurement.

Size: 1/8″-120″
Accuracy: ¡À0.5%
Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Protection Grade: IP65 std, IP68 optional for remote
Velocity: 0.1~15 m/s
Conductivity: > 5 ¦ÌS/cm, demineralized water > 20 ¦ÌS/cm
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery
Size: DN3-DN3000
Sensor material: carbon steel (std), SS304 / SS316 (optional)
Flange: ANSI, DIN, JIS, etc.
Measuring tube: SS304
Function: High and low alarm, exciting alarm, empty pipe alarm, self-diagnosis

inline magnetic flow meter also known as electromagnetic flow meter or mag meter, is widely used because less obstruction, cost-effective and accurate measurement. Only the pulsation frequency is much lower than the excitation frequency. The meter output is essentially linear. It is easy to choose the type of material in contact with the fluid, which can be used for aggressive fluids.

Size: 1/8″-120″
Electrode: SUS316L, Hastelloy B, Hastelloy C
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS

Measurement of electromagnetic water meter is independent of fluid density, viscosity, temperature, pressure, and conductivity. Two measuring points inside the meter with no moving parts to eliminate pressure drop, Capable of measuring electric conductive liquid and fluids with low solid contents. liner of magmeter can be PTFE or rubber, our magnetic flow meter have been approved CE-LVD, CE-EMC, ATEX, NSF, tec. it can mag flowmeter is calibrationed 5 points.

Size: 1/8″-120″
Electrode: SUS316L, Hastelloy B, Hastelloy C
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS

mag flow meterinluding inserted flow and compact electromagnetic flow meter, while electromagnetic flow meters are designed to measure conductive liquids. Q&T instrument is OEM and OEM manufacturer of inline magnetic flowmeter with 17 years experience, standard cable length is 10m, widely used in water and waste water industry.

Structure: compact, remote
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Velocity: 0.1~15 m/s
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery

liquid flow meter including magnetic flow meter, ultrasonic flow meter, turbine flow meter, etc, while electromagnetic flow meter is widely used for conductive liquids, main components are sensor and transmitter, liquid flow meter is calibrted according to CNAS 17025.QTLD magmeter has been approved CE and Atex. electromagnetic flow meter don’t have any moving parts to wear down, reducing the need for maintenance or replacement.

Size: 1/8″-120″
Accuracy: ¡À0.5%
Repeatability: 0.17%
Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote

Newest Product Partial Filled Pipe Flow Meter Sewage Stainless Steel Variable Area Water Flowmeters RS485 flow meters is composed of converter, flow sensor and level sensor. The user only needs to
enter the diameter of pipe, the non-full pipe flowmeter will automatically calculate the flow rate, and automatically
display the instantaneous flow, total flow, velocity, height, etc. It can measure liquid volume min 10% of full pipe. It is
especially suitable for the needs of municipal rainwater, waste water, sewage discharge and irrigation

Q&T is manufacturer for flow meters, protection grade of magnetic flow meter sensor is IP68 for remote and IP65 for compact magnetic flow meter, sensor can be submerged in the water for 3m depth or buried underground, standard cable length is 10m, max cable length is 100m, Remote type liquid flow meter is recommended for large size.

Structure: compact, remote
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Velocity: 0.1~15 m/s
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery

Q&T series Electromagnetic Flowmeter has a number of advantages when it comes to liquid flow measurement. The sensors are generally inserted in line into the pipes’ diameter, and are therefore designed such that they do not disturb or restrict the flow of the medium under measurement. As the sensors are not directly immersed in the liquid-there are no moving parts-there are no wear and tear concerns.
Size: 1/8″-120″
Accuracy: ¡À0.5%
Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Protection Grade: IP65 std, IP68 optional for remote
Velocity: 0.1~15 m/s
Conductivity: > 5 ¦ÌS/cm, demineralized water > 20 ¦ÌS/cm
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery
Size: DN3-DN3000
Sensor material: carbon steel (std), SS304 / SS316 (optional)
Flange: ANSI, DIN, JIS, etc.
Measuring tube: SS304
Function: High and low alarm, exciting alarm, empty pipe alarm, self-diagnosis

inserted magnetic flow meter can be compact type and remote type, standard cable length is 10m and max cable length is 120m. Q&T instrument is OEM and OEM manufacturer of inline magnetic flowmeter with 17 years experience, standard cable length is 10m, widely used in water and waste water industry.
Size: DN100-DN3000
Probe: ABS, PVC
Flange: ANSI, DIN, JIS, etc.
Measuring tube: SS304
Function: High and low alarm, exciting alarm, empty pipe alarm, self-diagnosis

Standard flow sensor of mag flowmeter is carbon steel, SS304 and SS316 is optional, liner material is PTFE, which approved NSF and FDA, inline magnetic flow meter can be used for drinking water. Q&T Instrument have large stock for varous flow meters and level meters, goods can be delivered with in 4 days for regular types.
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Protection Grade: IP65 std, IP68 optional for remote
Velocity: 0.1~15 m/s
Conductivity: > 5 ¦ÌS/cm, demineralized water > 20 ¦ÌS/cm

magnetic flowmeter can be customized color and logo,Q&T Instrument is OEM for many European and Amercian brands. 2 years warranty. our main products are electromagnetic flow meter, ultrasonic flowmeter, vortex flow meters, turbine flowmeters, thermal mass flow meters, variable area flow meters, which widely used for water and gas.
Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS

Q&T series superior sensor design withstands the harshest environmental conditions. Industry optimized liner and electrode materials and resistance to abrasion and corrosion.Q&T series Digital Magnetic Flow Meter has the long-term high accuracy of measurement. It actually is not affected by fluid physical properties. Measurement accuracy can be up to 1%, 0.5%.Q&T series superior converter adopts surface mount technology (SMT), with self-check and self-diagnosis functions.

Size:DN3-3000mm
Material:Carbon Steel SS304 S316
Dual Power:24V/220V
Nominal Pressure: 0.6-1.6Mpa(Max 42Mpa)
Accuracy: +/-0.5%(Standard)0.2% (Optional)
Liner: PTFE, Neoprene, Hard Rubber, EPDM, FEP, Polyurethane, PFA
Electrode Material:SUS316L,Hastelloy B,Hastelloy C,Titanium,Tantalum,Platinum-iridium
Output Signal: 4-20mA/Pulse
Ambient Temperature:-20~+60deg C

electromagnetic flowmeter can be used to measure the volume flow of conductive fluid in a closed pipeline. It is widely applied in the flow measurement and control in the fields of chemical and petroleum industry, metallurgy industry, water and wastewater, agriculture and irrigation, paper making, food and beverage industry and pharmaceutical industry, etc.
When the conductive fluid flows through the measuring tube of the sensor, the voltage signal in direct proportion to the average flow velocity of the fluid will be inducted on the electrodes. The signal is amplified and treated by the transmitter to realize various display functions.
Size: 1/8″-120″
Accuracy: ±0.5%
Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Protection Grade: IP65 std, IP68 optional for remote
Velocity: 0.1~15 m/s
Conductivity: > 5 μS/cm, demineralized water > 20 µS/cm
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery
Size: DN3-DN3000
Sensor material: carbon steel (std), SS304 / SS316 (optional)
Flange: ANSI, DIN, JIS, etc.

3.6V battery powered electromagnetic flowmeter could reach IP68 protection, put under water for long time, 3.6V battery powered magnetic flowmeter also have external DC12-24V power. Size: DN10-DN2000; Nominal Pressure: 0.6-1.6MPa(2.5Mpa / 4.0Mpa /6.4Mpa…Max 42Mpa); Accuracy: ¡À0.5% (Standard), ¡À0.3% or ¡À0.2% (Optional); Structure: Integral,remote,submersible,ex-proof; Medium Temperature: -20¡æ~+60¡æ (integral type), Remote type(neoprene,Hard rubber,Polyurethane, EPDM) -10¡æ~+80¡æ; Remote type (PTFE / PFA / FEP)-10¡æ~+160¡æ; Protection Class: IP65(Standard),IP68(Optional for remote type); Output Signal: 4-20mA / pulse (optional); Communication: RS485(Optional),HART(Optional),GPRS/GSM (Optional);

Battery power electromagnetic flow meter satisfy water fee calculation with high accuracy,3.6V magmeter is widely used in applications without power grid, can work with solar power supply. Accuracy: ¡À0.5% (Standard), ¡À0.3% or ¡À0.2% (Optional); Ambient Humidity: 5-100%RH (relative humidity); Protection Class: IP65(Standard), IP68(Optional for remote type); Process Connection: Flange(Standard),Wafer,Thread,Tri-clamp etc(optional); Output Signal: 4-20mA / pulse (optional); Communication: RS485(Optional),HART(Optional),GPRS/GSM(Optional); Power Supply: Battery powered 3.6V,Battery powered 3.6V +DC24V(Optional); Power Consumption: 0.5W(Standard),1.5W(with DC24V);

Q&T’s battery magnetic flow meter comes standard with a rugged IP68 die-cast aluminum enclosure,which allows the device to be used in both indoor and outdoor applications. Size: DN10-DN2000; Accuracy: ¡À0.5% (Standard), ¡À0.3% or ¡À0.2% (Optional); Protection Class: IP65(Standard),IP68(Optional for remote type); Process Connection: Flange(Standard),Wafer,Thread,Tri-clamp etc(optional); Output Signal: 4-20mA / pulse (optional); Communication: RS485(Optional),HART(Optional),GPRS/GSM(Optional); Power Supply: Battery powered 3.6V, Battery powered 3.6V +DC24V(Optional); Power Consumption: 0.5W(Standard), 1.5W(with DC24V);

Electromagnetic water meter have the functions such as higher integration ,fast in operational speed ,best accuracy in calculation ,digital signal processing ,strong capability of interference immunity ,stable and reliable measurement
Electromagnetic water meter GSM/GPRS remote monitoring management can set multiple operators at different levels, play data hierarchical management, and realize data sharing of user LAN.

LCD display, display Cumulative flow,lnstantaneous flow Forward flow, Reverseflow
Units: L/h. L/m. L/s. m3/h. m3/m. m 3/s.GPM
Language: English, ltalian, Spanish,Russian Japanese, Korean, etc.

electromagnetic flow meter can be configured yellow or green OLED display, SD card or GPRS to monitor history record, bluetooth is convenient to check flow. Magnetic flow meter can be solar-powered, solar panel can be customized according to client request, like work last 2 days, 5 days, 7 days, etc. Transmitter of electromagnetic flow meter is installed in the cabinet to protect rain and sun.
Accuracy: ¡À0.5%
Repeatability: 0.17%
Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic

The magneric flow meter is one of the most flexible and unversally applicable flow measurement
systems available. It is volumtric flow meter which does not have any moving parts and is ideal for
waste water applications or any dirty liquid which is conductive or waste based. Magnetic flow meter
is also ideal for the applications where low meter is also ideal for the applications where low pressure
drop and low maintrnance are reequired.
Size: 1/8″-120″
Accuracy: ±0.5%
Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Protection Grade: IP65 std, IP68 optional for remote
Velocity: 0.1~15 m/s
Conductivity: > 5 μS/cm, demineralized water > 20 µS/cm
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery
Size: DN3-DN3000
Sensor material: carbon steel (std), SS304 / SS316 (optional)
Flange: ANSI, DIN, JIS, etc.

Process connection of inline magnetic flow meter is flange, tri-clamp, wafer, thread, etc. we use mass method, pulse or comparison method to calibrate, each flow meter have calibration certificate together with goods. 5 points are calibrated for magnetic flowmeter. widely used for conductive liquids. electromagnetic flowmeter is composed by magnetic flow meter and pt1000 temeprature sensor, can calibrated on liquid test bench, standard accuracy is ¡À0.5%

Structure: compact, remote
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Velocity: 0.1~15 m/s
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery

QTLD magnetic flowmeter, also known as electromagnetic flow meter or mag meter, is widely used because less obstruction, cost-effective and accurate measurement. Electromagnetic flow meter don’t have any moving parts to wear down, reducing the need for maintenance or replacement. We offer flowmeters with a range of liners, electrodes, and sizes, which can meet various conductive liquids.

Accuracy: ¡À0.5%
Structure: compact, remote
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Protection Grade: IP65 std, IP68 optional for remote
Velocity: 0.1~15 m/s

Size DN50 to DN300 pipe line
Suitable for all conductive liquids
No moving parts
Near zero pressure drop
Wide range in electrode: SS316, Ti, HC, HB, Ta, Pt
Multi-choice in flange: DIN, GB, ANSI, JIS, EN, etc

Application: Outdoor,underground.Especially
Without power supply places.
Battery Powered: 3.6V lithium battery
Communication Interface:RS485
Wireless Communication:GSM¡¢GPRS¡¢CDMAProtection:IP68

Q&T have 8 sets calibration device for liquids mag flowmeter and 5 sets calibration equipments for gas. our calibration lab has been approved CNAS ISO/IEC 17025:2017. magnetic flow meter can add pt1000 temeprature sensor to be magnetic btu meter to monitor flow and btu of hot water and cold water, can calibrated on liquid test bench, standard accuracy is ¡À0.5%

Repeatability: 0.17%
Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Output Signal: 4~20 mA, Pulse

Magnetic flow meter battery satisfy urban water supply to ensure accurate water fee calculation,magnetic flowmeter battery is specially used in no power supply region. Structure: Integral,remote,submersible,ex-proof; Ambient Humidity: 5-100%RH (relative humidity); Protection Class: IP65(Standard), IP68(Optional for remote type); Process Connection: Flange(Standard),Wafer,Thread,Tri-clamp etc(optional); Output Signal: 4-20mA / pulse (optional); Communication: RS485(Optional),HART(Optional),GPRS/GSM(Optional); Power Supply: Battery powered 3.6V,Battery powered 3.6V +DC24V(Optional); Power Consumption: 0.5W(Standard),1.5W(with DC24V);

The Electromagnetic flow meter has the feature of high accuracy and reliability. This magnetic flow sensor is suitable for measuring the flow of liquids, pastes, and slurries in water, chemical, food, pharmaceutical,mining, and agricultural industries etc. The structure of the digital water flow meter has integral type and remote type.

Specifications:
Place of Origin:Henan, China
Brand Name: Q&T
Model Number: QTLD
Accuracy: 0.5%, optional 0.2%
Signal output: 4~20 mA, pulse
Power supply: 220VAC, 24VDC
Body material: Carbon steel
Liner material: PTFE, FEP, PFA, CR, hard rubber, PU, FLS
Electrode material: SUS316L, HC, HB, Ti, Tan, Pt
Connection: Flange, thread, wafer, tri-clamp, union
Protection grade:IP65 / IP 68(optional)

Battery power mag flowmeter is designed for calibration of flow meters under controlled and stable flow conditions.3.6V magmeter provide obstruction free flow measurement. Electrode: SUS316L,Hastelloy B,Hastelloy C, Titanium,Tantalum,Platinum-iridium; Protection Class: IP65(Standard),IP68(Optional for remote type); Process Connection: Flange(Standard),Wafer,Thread,Tri-clamp etc(optional); Output Signal: 4-20mA / pulse (optional); Communication: RS485(Optional),HART(Optional),GPRS/GSM(Optional); Power Supply: Battery powered 3.6V,Battery powered 3.6V +DC24V(Optional); Power Consumption: 0.5W(Standard), 1.5W(with DC24V); Explosion Proof: ATEX

Q&T’s magnetic flowmeter battery each set will have well calibrated before leave factory, mag flow meter battery adopt pulse calibration, with weighing method, guarantee the 0.5% accuracy. Accuracy: ¡À0.5% (Standard),¡À0.3% or ¡À0.2% (Optional); Liner: PTFE,Neoprene,Hard Rubber,EPDM,FEP,Polyurethane,PFA; Electrode: SUS316L,Hastelloy B,Hastelloy C,Titanium,Tantalum,Platinum-iridium; Ambient Temperature: -20¡æ~+ 60¡æ; Ambient Humidity: 5-100% RH (relative humidity); Process Connection: Flange(Standard),Wafer,Thread,Tri-clamp etc(optional); Output Signal: 4-20mA/pulse (optional);
