waste water flange connection electromagnetic flowmeter

DC3.6V powered electromagnetic flowmeter could reach IP68 protection,3.6V battery powered mag flow meter could put under water for long time, flow meter also have external DC12-24V power. Size: DN10-DN2000; Nominal Pressure: 0.6-1.6MPa(2.5Mpa / 4.0Mpa /6.4Mpa…Max 42Mpa); Accuracy: ¡À0.5% (Standard), ¡À0.3% or ¡À0.2% (Optional); Structure: Integral,remote,submersible,ex-proof; Medium Temperature: -20¡æ~+60¡æ (integral type), Remote type(neoprene,Hard rubber,Polyurethane, EPDM) -10¡æ~+80¡æ; Remote type (PTFE / PFA / FEP)-10¡æ~+160¡æ; Protection Class: IP65(Standard),IP68(Optional for remote type); Output Signal: 4-20mA / pulse (optional); Communication: RS485(Optional),HART(Optional),GPRS/GSM (Optional);

All transmitters will be tested in the high and low temperature sensor cabinet, Inside inserted electromagnetic flow meter, there is an electromagnetic coil that generates a magnetic field, and electrodes that capture electromotive force(voltage), QTLD water flow meter inluding inserted flow and compact electromagnetic flow meter, vortex flow meter, metal tube rotameter, ultrasonic flow meter.
Size: 1/8″-120″
Accuracy: ¡À0.5%
Structure: compact, remote
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Velocity: 0.1~15 m/s

flange connection magnetic flow meter can display Instantaneous flow, total flow, flow velocity. mag flowmeters have function of high and low alarm, empty pipe alarm, exciting alarm and self-diagnosis.
Structure: compact, remote
Size: DN3-DN3000
Communication: RS485, HART, PROFIBUS
Protection Grade: IP65 std, IP68 optional for remote

“Q&T series Electromagnetic flowmeters for the accurate flow measurement of any conductive fluid, Ideally suited to water and waste water treatment plants, mining and general industry.Q&T series Electromagnetic flowmeters transmitter display guides operator with menu prompts during configuration.
Comprehensive output options, Include multiple analogue, relay, digital and serial outputs.”
Size: 1/8″-120″
Accuracy: ±0.5%
Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Protection Grade: IP65 std, IP68 optional for remote
Velocity: 0.1~15 m/s
Conductivity: > 5 μS/cm, demineralized water > 20 µS/cm
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery
Size: DN3-DN3000
Sensor material: carbon steel (std), SS304 / SS316 (optional)
Flange: ANSI, DIN, JIS, etc.
Measuring tube: SS304
Function: High and low alarm, exciting alarm, empty pipe alarm, self-diagnosis

Magnetic flow meter battery satisfy urban water supply to ensure accurate water fee calculation,magnetic flowmeter battery is specially used in no power supply region. Structure: Integral,remote,submersible,ex-proof; Ambient Humidity: 5-100%RH (relative humidity); Protection Class: IP65(Standard), IP68(Optional for remote type); Process Connection: Flange(Standard),Wafer,Thread,Tri-clamp etc(optional); Output Signal: 4-20mA / pulse (optional); Communication: RS485(Optional),HART(Optional),GPRS/GSM(Optional); Power Supply: Battery powered 3.6V,Battery powered 3.6V +DC24V(Optional); Power Consumption: 0.5W(Standard),1.5W(with DC24V);

mag flowmeter is consist of sensor, transmitter and Pt1000 temperature sensor. magnetic heat meter is available for use in pipes ranging in size from DN100 to DN3000, which also can monitor flow and energy of hot water and cold water, standard configuration of flange and sensor shell is carbon steel, SS304 and SS316L are optional.

Size: 1/8″-120″
Accuracy: ¡À0.5%
Repeatability: 0.17%
Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote

insertion electromagnetic flow meter is used to measure the flow of conductive liquids. It is available for use in pipes ranging in size from DN100 to DN3000, insertion magnetic flowmeter can configure thread or flange ball valve to be hot-tapped, which allows sensor to be installed and retracted from process piping without shutting down the process.
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Protection Grade: IP65 std, IP68 optional for remote

electromagnetic flowmeter is composed by transmitter and sensor. standard configuration is carbon steel sensor, SS316L electrodes and PTFE liner. A magnetic flowmeter 41 calibrator simulates the signal provided by the electrodes in the flow tube. The operating voltage and frequency range of the calibrator must match those of the magnetic flowmeter. Select the maximum output signal using the calibrator range switch.

Size: 1/8″-120″
Accuracy: ¡À0.5%
Structure: compact, remote
Velocity: 0.1~15 m/s
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery
Sensor material: carbon steel (std), SS304 / SS316 (optional)
Measuring tube: SS304

QTLD magnetic flowmeter, also known as electromagnetic flow meter or mag meter, is widely used because less obstruction, cost-effective and accurate measurement. Electromagnetic flow meter don’t have any moving parts to wear down, reducing the need for maintenance or replacement. We offer flowmeters with a range of liners, electrodes, and sizes, which can meet various conductive liquids.

Accuracy: ¡À0.5%
Structure: compact, remote
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Protection Grade: IP65 std, IP68 optional for remote
Velocity: 0.1~15 m/s

mag flow meterinluding inserted flow and compact electromagnetic flow meter, while electromagnetic flow meters are designed to measure conductive liquids. Q&T instrument is OEM and OEM manufacturer of inline magnetic flowmeter with 17 years experience, standard cable length is 10m, widely used in water and waste water industry.

Structure: compact, remote
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Velocity: 0.1~15 m/s
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery

Electromagnetic water meter is a fully intelligent developed by our company using the most advanced technology at home and abroad. Its electromagnetic converter core adopts high-speed central processing unit. The calculation speed is very fast, the precision is high, and the measurement performance is reliable.
1) Measurement is not affected by the flow density, viscosity, temperature, pressure and conductivity.
2) Do not require much upstream and downstream straight run can be installed in relatively short meters.
3) Wide range of pipe size DN50-300 are available.

Process connection of inline magnetic flow meter is flange, tri-clamp, wafer, thread, etc. we use mass method, pulse or comparison method to calibrate, each flow meter have calibration certificate together with goods. 5 points are calibrated for magnetic flowmeter. widely used for conductive liquids. electromagnetic flowmeter is composed by magnetic flow meter and pt1000 temeprature sensor, can calibrated on liquid test bench, standard accuracy is ¡À0.5%

Structure: compact, remote
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Velocity: 0.1~15 m/s
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery

Battery powered magnetic flow meter is designed for calibration of flow meters under controlled and stable flow conditions.Battery meters provide obstruction free flow measurement. Electrode: SUS316L,Hastelloy B,Hastelloy C, Titanium,Tantalum,Platinum-iridium; Protection Class: IP65(Standard),IP68(Optional for remote type); Process Connection: Flange(Standard),Wafer,Thread,Tri-clamp etc(optional); Output Signal: 4-20mA / pulse (optional); Communication: RS485(Optional),HART(Optional),GPRS/GSM(Optional); Power Supply: Battery powered 3.6V,Battery powered 3.6V +DC24V(Optional); Power Consumption: 0.5W(Standard), 1.5W(with DC24V); Explosion Proof: ATEX

Q&T series electromagnetic flow meter main application range of MAGYN widely covers a variety of fields:
*Chemical and petroleum industry
? Metallurgy industry
? Water and waste water
? Agriculture and irrigation
? Food and beverage industry
? Pharmaceutical industry

Size:DN3-3000mm
Material:Carbon Steel SS304 S316
Dual Power:24V/220V
Nominal Pressure: 0.6-1.6Mpa(Max 42Mpa)
Accuracy: +/-0.5%(Standard)0.2% (Optional)
Liner: PTFE, Neoprene, Hard Rubber, EPDM, FEP, Polyurethane, PFA
Electrode Material:SUS316L,Hastelloy B,Hastelloy C,Titanium,Tantalum,Platinum-iridium
Output Signal: 4-20mA/Pulse
Ambient Temperature:-20~+60deg C

Battery powered magnetic flowmeter also could measure & display temperature and pressure, humanized human-computer interaction interface, battery flow meter enjoy easy operation. Nominal Pressure: 0.6-1.6MPa(2.5Mpa / 4.0Mpa /6.4Mpa…Max 42Mpa); Accuracy: ¡À0.5% (Standard), ¡À0.3% or ¡À0.2% (Optional); Liner: PTFE, Neoprene,Hard Rubber,EPDM,FEP, Polyurethane,PFA; Electrode: SUS316L,Hastelloy B,Hastelloy C, Titanium,Tantalum,Platinum-iridium; Structure: Integral,remote,submersible,ex-proof; Process Connection: Flange(Standard),Wafer,Thread,Tri-clamp etc(optional); Output Signal: 4-20mA / pulse (optional); Communication: RS485(Optional),HART(Optional),GPRS/GSM(Optional);

With simple structure ,the flow meter is of high reliability without lining in the measuring pipe .
The wide range of the nominal bore is suitable for all the pipe size between DN50 and DN300.

Measurement of mag flowmeter is independent of fluid density, viscosity, temperature, pressure, and conductivity. Two measuring points inside the meter with no moving, parts to eliminate pressure drop
Capable of measuring electric conductive liquid and
fluids with low solid contents
Size: 1/8″-120″
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery
Sensor material: carbon steel (std), SS304 / SS316 (optional)
Measuring tube: SS304

Electromagnetic flowmeters. Measuring for process management, revenue collection, liquid transportation and energy conservation. water flow meter is widely used because less obstruction, cost-effective and accurate measurement. Magnetic flowmeter don’t have any moving parts to wear down, reducing the need for maintenance or replacement.

Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Protection Grade: IP65 std, IP68 optional for remote
Velocity: 0.1~15 m/s

magmeter is calibrated on ¡À0.2% accuracy test bench, electromagnetic flowmeter is calibrationed 5 points. our calibration lab has been approved CNAS ISO/IEC 17025:2017. Q&T Instrument has large stock fro varous flanges for different water flow meters, like magnetic fflow meter, turbine flow meter, oval gear flow meter, etc.

Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery
Size: DN3-DN3000
Sensor material: carbon steel (std), SS304 / SS316 (optional)
Measuring tube: SS304

The magnetic flow meter is installed in the well to measure water, the protection grade is IP68 and it can be submered in the water.The magnetic water meter has wide measuring range, Q3:Q1 is R400, the flow sensor can be desired to be full bore and reduced bore, while reduced bore don’t need any straight pipe in the upstream and downstream.

Size: 1/8″-120″
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery
Size: DN3-DN3000
Measuring tube: SS304

Electromagnetic water meter be used to measure the volume flow of strongly corrosive liquids such as strong acids and alkalis and smooth liquid-solid two-phase suspension liquids such as mud, mineral pulp, and paper pulp. It is widely used in flow measurement in petroleum, chemical, metallurgy, textile, paper and others.
High definition LCD display with backlight.
RS485 or RS232 interface supports digital communication.
Intelligent empty pipe detection and electrodes resistance measurement diagnosing
empty pipe and electrodes contamination accurately.

Electromagnetic water meter is used to measure the flow of conductive fluid in watersupply,steel£¬petroleum,chemical industry,electric power£¬industry£¬water conservancyand other departments.

Electromagnetic water meter is widely used in the fields of petroleum, chemical industry, metallurgy, textile, pharmacy, food and beverage, paper making, electric power, urban water supply and drainage and environmental protection.
Customized colors for all electromagnetic flow meters
DN50-DN300 wide ranges.
Modbus RS485,pulse output
Drink water, waste water, sea water, beer, juice, chemical and conductive liquids.

Q&T Instrument has large stock for varous flanges for different electromagnetic flowmeter, like DIN, ANSI, JIS, etc. PTFE, neoprene liner and other liners are optional, Liner of mag flowmeter has been approved NSF or FDA certificate. it can be used to measure driing water. it has function of high and low alarm, empty alarm, excitation alarm, etc.

Size: DN3-DN3000
Accuracy: ¡À0.5%
Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS

Q&T series Electromagnetic flowmeters for the accurate flow measurement of any conductive fluid, Ideally suited to water and waste water treatment plants, mining and general industry.Q&T series Electromagnetic flowmeters offer a high quality, economic and solid state solution for measuring flow in areas where flow sensors with moving parts cannot be applied.

Size:DN3-3000mm
Material:Carbon Steel SS304 S316
Dual Power:24V/220V
Nominal Pressure: 0.6-1.6Mpa(Max 42Mpa)
Accuracy: +/-0.5%(Standard)0.2% (Optional)
Liner: PTFE, Neoprene, Hard Rubber, EPDM, FEP, Polyurethane, PFA
Electrode Material:SUS316L,Hastelloy B,Hastelloy C,Titanium,Tantalum,Platinum-iridium
Output Signal: 4-20mA/Pulse
Ambient Temperature:-20~+60deg C

Standard material of waste water flow meter is carbon steel, but client can chose stainless steel 304 or SS316.

electromagnetic flow meter can be configured yellow or green OLED display, SD card or GPRS to monitor history record, bluetooth is convenient to check flow. magnetic flowmeter can be solar-powered, solar panel can be customized according to client requirement from 1 to 15 days. Q&T is professional manufacturer of flow meters and level meters.

Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS

QTLD magnetic flow meter can be compact or remote, it’s configured PTFE liner and Tantalum electrodes to be anti-corrosive. liquid flow meter is calibrted according to CNAS 17025.QTLD magmeter has been approved CE and Atex. electromagnetic flow meter don’t have any moving parts to wear down, reducing the need for maintenance or replacement.

Size: 1/8″-120″
Accuracy: ¡À0.5%
Repeatability: 0.17%
Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote

magentic water flow meter is volumetric flow meter, it does not have any moving parts and is ideal for wastewater applications or any dirty liquid that is conductive or water-based. magmeter manage critical flow applications to improve accuracy, decrease system maintenance and meet the demands of challenging liquid conditions.
Conductivity: > 5 ¦ÌS/cm, demineralized water > 20 ¦ÌS/cm
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery
Size: DN3-DN3000
Sensor material: carbon steel (std), SS304 / SS316 (optional)
Flange: ANSI, DIN, JIS, etc.

Q&T series magneric flow meter is one of the most flexible and unversally applicable flow measurement
systems available. It is volumtric flow meter which does not have any moving parts and is ideal for
waste water applications or any dirty liquid which is conductive or waste based. Q&T series Magnetic flow meter
is also ideal for the applications where low meter is also ideal for the applications where low pressure
drop and low maintrnance are reequired.

Size: 1/8″-120″
Accuracy: ±0.5%
Electrode: SUS316L, Hastelloy B, Hastelloy C
Structure: compact, remote
Liner: PTFE, PFA, Polyurethane, Neoprene, Hard Rubber, Ceramic
Output Signal: 4~20 mA, Pulse
Communication: RS485, HART, PROFIBUS
Protection Grade: IP65 std, IP68 optional for remote
Velocity: 0.1~15 m/s
Conductivity: > 5 μS/cm, demineralized water > 20 µS/cm
Power supply: 85~250 VAC, 20V~36VDC, 3.6V lithium battery
Size: DN3-DN3000
Sensor material: carbon steel (std), SS304 / SS316 (optional)
Flange: ANSI, DIN, JIS, etc.
Measuring tube: SS304
Function: High and low alarm, exciting alarm, empty pipe alarm, self-diagnosis
